DM318

Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number :
Category :
DMR Radio
Quantity
-
+
Stock:
0
1
Product description
Parameters
Special feature
General parameters
Accessories
Scan the QR code to read on your phone
We could not find any corresponding parameters, please add them to the properties table

Compatible with Motorola DMR radio in voice and message

IP67 (Dust-protection and water resistant)

CTCSS/DCS (Analog)

Kill/Revive

Radio Disable Decode

Remote Monitor Decode

Emergency Remote Moinot Decode

Alarm Type selective

Revert Channel

Private Call/Group Call/All call (Digital mode)

Emergency System

Private Call Confirmed

Battery Save/Indicator/Warning

Emergency

Monitor

Repeater Talkaround

Scan On/Off

Zone Selection

Text message

GPS Localization (Optional)

Recording & Play back(Optional)

Model MYT-DM318(Portable)
General Specifications
Power Supply 7.5V DC ±20%
Frequencies - Full Bandsplit 136-174MHz/400-470MHz
450-520MHz/350-400MHz
Number of Channels 256 channels
Maximum number of Zones 16
Maximum number of Channels Per Zone 16
Channel Spacing 12.5/25kHz
Operating Temperature -25~ + 60
Dimensions: H x W x D (mm) 138 x 60 x 41 (mm)
Weight: (g) 301g
Battery capacity 2000mAh Li-ion (Standard), 2600mAh Li-ion(Optional)
Transmitter Specifications
Frequency Stability(-30℃ to 60℃, 25℃ Ref) 1.25ppm
Power Output 1W(L),4or5W(H)
4FSK Digital Modulation 12.5KHz Data Only:7K60FXD
12.5KHz Data & Voice:7K60FXW
Digital Vocoder Type AMBE++ or SELP
Digital Protocol ETSI-TS102 361-1,-2,-3
Modulation Limiting ±2.5kHz@12.5kHz
FM Hum & Noise -40dB
Conducted/Radiated Emission -36dBm < 1GHz, -30dBm > 1GHz
Adjacent Channel Power -60dB
Adjacent Transient Channel Power -50dB
Audio Response (300-3000Hz) +1 ~ -3 dB
Audio Distortion < 5%
Receiver Specifications
Analog Sensitivity 0.35μV/-116dBm(20 dB SINAD) .22μV/-122dBm(12 dB SINAD)
DigitalSensitivity 0.3μV /-117.4dBm (BER 5%)
Intermodulation TIA603 70 dB; ETSI 65dB
Adjacent Channel Selectivity 60dB
Spurious Rejection 70 dB
Blocking 80 dB
Rated Audio 1000mW
Audio Distortion @ Rated Audio 3%
Audio Response (300-3000Hz) +1 ~ -3 dB
Conducted Spurious Emission -57 dBm<1 GHz, -47 dBm>1GHz   ETS 300 086
